ADR233B
Contents
7 COMMUNICATIONS 185
7.1 IRIG TIME CODE DESIGNATIONS 188
7.2 MODBUS 189
7.2.1 MODBUS Protocol Map 190
7.3 IEC60-870-5-103 201
7.3.1 Physical Connection and Link Layer 201
7.3.2 Initialisation 202
7.3.3 Time Synchronisation 202
7.3.4 Spontaneous Events 202
7.3.5 General Interrogation (GI) 202
7.3.6 Cyclic Measurements 203
7.3.7 Commands 203
7.3.8 Disturbance Records 203
7.3.9 Protocol Mapping: 203
7.4 IEC 61850 216
7.4.1 Protocol map 216
