Ashida ADR233B - Page 259

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 259 of 479
ADR233B
option.
General Settings
System Frequency
50Hz
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the System Frequency can be set i.e. 50Hz
/ 60Hz.
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
Opto I/P Supply
DC
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Opto I/P Supply can be set i.e. DC / AC.
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
W1 CB Operation
No Operation
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 CB Operation can be set i.e. CB
Open / CB Close / No Operation.
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
W2 CB Operation
No Operation
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 CB Operation can be set i.e. CB
Open / CB Close / No Operation.
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
PB-1 Operation
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the PB–1 Operation can be set i.e. No
Operation / Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
