Ashida ADR233B - Page 260

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 260 of 479
ADR233B
General Settings
tPB-1 Pulse
0.50 s
Range 0.1 – 50s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tPB–1 Pulse can be set. The setting
range is from 0.10s to 50s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
PB-2 Operation
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the PB–2 Operation can be set i.e. No
Operation / Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
tPB-2 Pulse
0.50 s
Range 0.1 – 50s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tPB–2 Pulse can be set. The setting
range is from 0.10s to 50s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
Config Port
PORT F
Read-only
This window shows the Config Port of the relay.
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
Timesync Master
PORT F
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Timesync Master can be set i.e. PORT
F/ PORT 1 / PORT R / IRIG-B.
Press the Minus / Down arrow key (- /) to move to the next
option.
General Settings
Description
ASHIDA ADR233B E0
Read-only
This window shows the Description of the relay.
Press the Minus / Down arrow key (- /) to move to the next
option.
