Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
145
of 820
4
with:
I
sq M-limit
Torque current limit from torque limit 138.22, in A
M
limit
Torque limit symmetric, 138.22, in Nm
Flux
set
Magnetic flux set value in % Z146.13–
Kt Kt = Kt
corr
· Kt factor, in Nm/A
Kt
corr
Kt correction factor, Z138.23–
Kt factor Motor Kt in Nm/A: "Kt factor", Z107.44–
Furthermore, other settable torque limits are available that result from the setting of the
torque current limit (
Z138.2–, Z138.3–, Z138.14–, Z138.15–). Furthermore, other
torque current limits are available Z138.18–, Z138.30–, Z114.5– and Z114.6– that limit
the torque due to a breakdown torque or an U
dc
actual value. The torque can be disabled
due to a power failure refer to
Z138.10– bit 1).
The strongest limit is effective.
The exact correlation between the torque current and the torque is shown in the torque
monitoring (
ZFig. 174– on page 524).
138.24 Indication threshold torque
If the absolute value of the effective torque (Z138.21–) exceeds the value of the torque
threshold, bit 0 in parameter Status current limitation (Z138.25–) is set.
138.25 Status current limitation
Status parameter for the functional block current limitation 
I
sq M-limit
M
limit
Kt
Flux
set
100
-----------------

----------------------------=
Bit no. Meaning
0 Indicates whether the absolute value of the effective torque (Z138.21–) is
greater or less than the set torque threshold (Z138.24–)
0: The torque is less than the torque threshold
1: Torque threshold exceeded
31 ... 1 Reserved
