BONFIGLIOLI Agile User Manual

Parameter list
Parameters
No.
Description
Unit
Setting range
Chapter
1192
Peak Current A
0.01% I
FIN
…
100000% o
c
I
FIN
7.2.2
Mux/DeMux
1250 Mux Input Index (write) -
EEPROM:
0 … 16
7.6.6.17
RAM:
17 … 33
1251 Mux Input Index (read) -
EEPROM:
0 … 16
7.6.6.17
RAM:
17 … 33
1252
Mux Inputs
-
Selection
7.6.6.17
1253
DeMux Input
-
Selection
7.6.6.17
User warnings
1363
User warning 1
-
Selection
7.6.6.14
1364
User warning 2
-
Selection
7.6.6.14
Convert PDP/internal
1370 In-F-PDP-word1 - Selection
7.10.12
1371
In-F-PDP-word2
-
Selection
7.10.12
1372
In-F-intern-long1
-
Selection
7.10.12
1373
In-F-intern-long2
-
Selection
7.10.12
1374
Convert-Reference
Hz
0.01 Hz…999.99 Hz
7.10.12
Modbus (RTU/ASCII)
1375
Modbus Parity
-
Selection
6.2.10.2
1376
Modbus Address
-
1 … 247
CM-Modbus
CANopen
1414
CANopen 0x3008 Perc. Actual
Value Source
- Selection
1415
CANopen 0x3011 Act.ValueWord 1
-
Selection
1416
CANopen 0x3012 Act.ValueWord 2
-
Selection
1417
CANopen 0x3021 Act.ValueLong 1
-
Selection
1418
CANopen 0x3022 Act. ValueLong 2
-
Selection
1420 CANopen Mux Input Index (write) -
EEPROM:
0 … 16
RAM:
17 … 33
1421 CANopen Mux Input Index (read) -
EEPROM:
0 … 16
RAM:
17 … 33
1422
CANopen Mux Inputs
-
Selection
CM-CAN
1423
CANopen Obj 0x3007 Actual Per-
centage Value Source
- Selection
1451
OS Synctime
-
700 … 900
CANopen
1432
IP Address
-
nnn.nnn.nnn.nnn
1433
Netmask
-
nnn.nnn.nnn.nnn
1434
Gateway
-
nnn.nnn.nnn.nnn
1435
DNS Server
-
nnn.nnn.nnn.nnn
1436
DHCP Option
-
Selection
1437
IP Command
-
Selection
Ethernet
1438
Reload IP-Settings
-
0 … 1
1440
Email function
-
Selection
1441
Email Text (Body)
-
Text
VABus (X21)
1500 VABus-X21 Baud rate - Selection
6.2.10.2
1501 VABus-X21 Node-ID - 1 … 30 CM-485
1502
VABus-X21 Watchdog Timer
s
0 … 1000
CM-485
Modbus (RTU/ASCII)
1503
Modbus Mode
-
Selection
6.2.10.2
1504 Modbus Baud rate Baud Selection CM-Modbus
1505 Modbus Watchdog Timer s 0 … 1000 CM-Modbus
352
Operating Instructions
Agile 06/2013 Parameters (Menu PARA)
