BONFIGLIOLI Agile User Manual

Commissioning
Fixed Frequencies
(Factory setting)
P480
Fixed Frequency 1
(0.00 Hz)
P481
Fixed Frequency 2
(10.00 Hz)
P482
Fixed Frequency 3
(25.00 Hz)
P483
Fixed Frequency 4
(50.00 Hz)
P485
Fixed Frequency 5
(5.00 Hz)
P486
Fixed Frequency 6
(10.00 Hz)
P487
Fixed Frequency 7
(25.00 Hz)
P488
Fixed Frequency 8
(50.00 Hz)
P66
7
Off
P66
P67
P131
Selection
P67
71
IN1D
0
0
0
P480
P131
72
IN2D
1
0
0
P481
73
IN3D (P558: 0 - Input)
1
1
0
P482
74
IN4D
0
1
0
P483
75
IN5D
0
1
1
P485
76
MFI1D(P452: 3 - NPN or 4 - PNP)
1
1
1
P486
77
MFI2D (P562: 3 - NPN or 4 - PNP)
1
0
1
P487
…
other signal sources
0
0
1
P488
Via the signal states at the digital inputs, the fixed frequencies can be selected.
P475 or P492: 3 - Fixed Frequency.
The Speed Control is always limited by the Minimum Frequency (P418) and Maximum
Frequency (P419).
Blocking Frequencies
(Factory setting)
Reference frequencies are hidden. Mechanical resonance of the plant can be avoided.
Two blocking frequencies can be set.
P447
1st Blocking Frequency (0.00 Hz)
P448
2nd Blocking Frequency (0.00 Hz)
P449
Frequency Hysteresis (0.00 Hz)
Select the frequency range to be hidden.
In this range, there is no stationary op-
erating point.
PWM input
A PWM signal at input IN2D (X11.5) can be used as reference value.
P496
10
PWM, 0 … 100%
of P419 (maximum frequency) or of P519 (maximum
reference percentage)
11
PWM, -100 … 100%
P652 and P653; for scaling
P476 or P494:
10
Repetition percentage
The Speed Control is always limited by the Minimum Frequency (P418) and Maximum
Frequency (P419).
Reference value
internal
Reference
value
output
P447
P449
P447 - P449
P449
f - hysteresis
Blocking
P447 + P449
f + hysteresis
Blocking
86
Operating Instructions
Agile 06/2013 After first commissioning
