BONFIGLIOLI Agile User Manual

Commissioning
Electronic gear
(Factory setting)
Chapter
Synchronization of drives.
Reference
value for
slave drive
Set P496 to "20 - repetition frequency single evaluation:" or "21 - Rep-
etition frequency double evaluation". IN2D (X11.5) is the frequency
input.
7.6.7
Set P497 (typically identical to P556 of the master drive).
7.6.7.2
Switch on
Set P475 or P492 to "40 - electr. gear".
7.5.1
Gear factor
Fixed
Set P689 to "1 - (P. 685 Numerator)/(P. 686 Denomina-
tor)". Set P685 and P686.
7.5.4.3.1
Variable
Set P689 to "2 - (Analog Numerator)/(P. 686 Denominator)"
or "3 - (P. 685 Numerator)/(Analog Denominator)". Set the
range via P687 and P688.
7.5.4.3.2
For P476 or P494, select a signal source. Via the signal
source the gear factor can be changed during operation.
7.5.2
Master drive
Output MFO1: Set P550 to "20 - Repetition Frequency MFO1F".
For P555, select a frequency source (1- Actual Frequency). Via P556,
set the output frequency.
7.6.3
Positioning
Chapter
P458 to "1 - Reference positioning". The reference point is detected via
digital input IN1D (terminal X11.4).
In P460, enter the travel distance in motor revolutions.
7.3.7
PLC: Logic functions and functions with analog quantities
Chapter/
instruc-
tion
Via graphic functional block programming or via entries in a table,
analog quantities can be influences and logic links to digital signals can
be created.
7.6.6.16,
PLC
1
1
Application manual "PLC".
95
Typical functions 06/2013 Operating Instructions
