Bosch VLS 5140 - 6 Dimensions; Dimensions for VLS 5140

1 689 978 572 2014-06-06| Robert Bosch GmbH
Dimensions | VLS 5140 | 53 en
6.1 Dimensions for VLS 5140
4800
152
2100
160
5770
2260
(850)
705
650
max. 2250
min. 1000
Fig. 22: Dimensional drawing 1
6. Dimensions
i All dimensions are stated in mm (millimeters).
! All dimensions given here are typical values.
Deviations are possible depending on the inclination
and nature of the floor, and production tolerances.
