Branson 2000Xc - Page 251

238 100-412-234 REV. 06
552 +S Energy Limit
The energy used in the
most recent weld was
greater than the upper
suspect limit you set.
Manually inspect the part
for a good weld. If you
encounter numerous or
successive alarms with
good parts, you might
change your suspect
energy limits.
553 - S Pk Power Limit
The peak power used in
the most recent weld was
less than the lower
suspect limit you set.
Manually inspect the part
for a good weld. If you
encounter numerous or
successive alarms with
good parts, you might
change your suspect peak
power limits.
554 +S Pk Power Limit
The peak power used in
the most recent weld was
greater than the upper
suspect limit you set.
Manually inspect the part
for a good weld. If you
encounter numerous or
successive alarms with
good parts, you might
change your suspect peak
power limits.
555 - S Col Dist Limit
The actual collapse
distance value did not
reach the minus suspect
collapse distance limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust
the collapse distance
value through the Alarm
Information screen or
Setup menu.
556 + S Col Dist Limit
The collapse distance
used in the most recent
weld was greater than
the upper suspect limit
you set.
Manually inspect the part
for a good weld. If you
encounter numerous or
successive alarms with
good parts, you might
change your suspect
collapse distance limits.
557 - S Abs Dist Limit
The absolute distance
used in the most recent
weld was less than the
lower suspect limit you
set.
Manually inspect the part
for a good weld. If you
encounter numerous or
successive alarms with
good parts, you might
change your suspect
absolute distance limits.
Table B.4 Suspect/Reject Alarms and Messages, with Probable Cause and Corrective Action
Alarm
ID
Display Message
Alarm Condition/
Cause
Corrective Action
