100-412-234 REV. 06 239
558 +S Abs Dist Limit
The absolute distance
used in the most recent
weld was greater than
the upper suspect limit
you set.
Manually inspect the part
for a good weld. If you
encounter numerous or
successive alarms with
good parts, you might
change your suspect
absolute distance limits.
559 - S Trg Dist Limit
The actual trigger
distance value did not
reach the minus suspect
trigger distance limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust
the Trigger Distance Limit
through the Alarm
Information screen or
Setup menu.
50A + R Col Dist Limit
The collapse distance
used in the most recent
weld was greater than
the upper reject limit you
set.
Discard the part. If you
encounter numerous or
successive alarms with
good parts, you might
change your reject
collapse distance limits.
50B - R Abs Dist Limit
The absolute distance
used in the most recent
weld was less than the
lower reject limit you set.
Discard the part. If you
encounter numerous or
successive alarms with
good parts, you might
change your reject
absolute distance limit.
50C +R Abs Dist Limit
The actual distance value
exceeded the plus reject
absolute distance limit.
Discard the part if you
encounter numerous or
successive alarms with
good parts. Consider
changing your Absolute
settings.
50E +R Trg Dist Limit
The actual trigger
distance value exceeded
the plus reject trigger
distance limit.
Adjust + reject trigger
distance limit through the
Alarm Information screen
or Setup menu. Discard
the part if you encounter
numerous or successive
alarms.
50F
- R Weld Force
Limit
The actual Weld Force did
not reach the minus
reject Weld Force limit.
Adjust - reject weld force
through the Alarm
Information screen or
Setup menu. Discard the
part if you encounter
numerous or successive
alarms.
Table B.4 Suspect/Reject Alarms and Messages, with Probable Cause and Corrective Action
Alarm
ID
Display Message
Alarm Condition/
Cause
Corrective Action
