55A + S Trg Dist Limit
The trigger distance used
in the most recent weld
was greater than the
upper suspect limit you
set.
Manually inspect the part
for a good weld. If you
encounter numerous or
successive alarms with
good parts, you might
change your suspect
trigger distance limits.
55B
- S Weld Force
Limit
The actual Weld Force did
not reach the minus
suspect Weld Force limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust
the Weld Force value
through the Alarm
Information screen or
Setup menu.
55C
+S Weld Force
Limit
The actual Weld Force
exceeded the plus
suspect Weld Force limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust
the Weld Force value
through the Alarm
Information screen or
Setup menu.
55D - S Time Limit
The time used in the
most recent weld was
less than the lower
suspect limit you set.
Inspect your parts. For
numerous or successive
alarms, you might adjust
the Time value through
the Alarm Information
screen or Setup menu.
55E +S Time Limit
The actual time value
exceeded the plus
suspect time limit.
Inspect your parts. For
numerous or successive
alarms, you might adjust
the Time value through
the Alarm Information
screen or Setup menu or
change suspect time
limits.
Table B.4 Suspect/Reject Alarms and Messages, with Probable Cause and Corrective Action
Alarm
ID
Display Message
Alarm Condition/
Cause
Corrective Action
