Branson 2000Xc - Page 255

242 100-412-234 REV. 06
207
+ - Time
Limit
Crossed
The suspect limits for time
that you have entered are
reversed.
Change the suspect time limits
through the Alarm Information
screen or Setup menu.
208
+ - Time
Limit
Crossed
The reject limits for time
that you have entered are
reversed.
Change the reject time limits
through the Alarm Information
screen or Setup menu.
209
+- Eng Limit
Crossed
The suspect limits for
energy that you have
entered are reversed.
Change the suspect energy
limits through the Alarm
Information screen or Setup
menu.
210
+ - Abs
Limit
Crossed
The suspect limits for
absolute distance that you
have entered are reversed.
Change the suspect absolute
distance limits through the
Alarm Information screen or
Setup menu.
211
+ - Col Limit
Crossed
The reject limits for collapse
distance that you have
entered are reversed.
Change the reject collapse
distance limits through the
Alarm Information screen or
Setup menu.
212
+ - Col Limit
Crossed
The suspect limits for
collapse distance that you
have entered are reversed.
Change the suspect collapse
distance limits through the
Alarm Information screen or
Setup menu.
213
+ - F Limit
Crossed
The minus reject weld force
limit is equal to or greater
than the plus reject weld
force limit.
Change the - reject weld force
limit and/or the +reject weld
force limit through the Alarm
Information screen or Setup
menu.
214
+ - F Limit
Crossed
The minus suspect force
limit is equal to or greater
than the plus suspect force
limit.
Change the - suspect weld
force limit and/or the +suspect
weld force limit.through the
Alarm Information screen or
Setup menu.
215
Amp Step
Conflict
The time that you have set
for the amplitude to step is
greater than the time that
you have set for the weld
cycle.
Change the step time for the
amplitude and/or the time
setting for the weld cycle.
216
Amp Step
Conflict
The amplitude step value is
equal to or greater than the
plus reject peak power limit
value.
Change the amplitude step or
+reject peak power limit
through the Alarm Information
screen or Setup menu.
217
Amp Step
Conflict
The amplitude step value is
equal to or greater than the
plus suspect peak power
limit.
Change the amplitude step or
+suspect peak power limit
through the Alarm Information
screen or Setup menu.
Table B.5 Setup Alarms and Messages, with Probable Cause and Corrective Action (Continued)
Alarm
ID
Display
Message
Alarm Condition/Cause Corrective Action
