Branson 2000Xc - Page 256

100-412-234 REV. 06 243
218
Amp Step
Conflict
The amplitude step value is
equal to or greater than the
plus reject energy limit.
Change the amplitude step or
+reject energy limit through
the Alarm Information screen
or Setup menu.
219
Amp Step
Conflict
The amplitude step value is
equal to or greater than the
plus suspect energy limit.
Change the amplitude step or
+suspect energy limit through
the Alarm Information screen
or Setup menu.
226
Amp Step
Conflict
The amplitude step at
power value is equal to or
greater than the peak
power value. This alarm is
for peak power mode only.
Change the amplitude step or
peak power main parameter
through the Alarm Information
screen or Setup menu.
227
Amp Step
Conflict
The amplitude step at
energy value is equal to or
greater than the max
energy compensation value.
Change the amplitude step or
maximum energy
compensation limit through the
Alarm Information screen or
Setup menu.
229
Amp Step
Conflict
The amplitude step value is
equal to or greater than the
peak power cutoff value.
This alarm is in all modes
but peak power.
Change the amplitude step or
peak power cutoff through the
Alarm Information screen or
Setup menu.
231
Amp Step
Conflict
The energy level you have
set for the amplitude to
step is in conflict with the
energy level you have set
for the weld cycle.
Change the step energy for the
amplitude and/or the energy
level for the weld cycle.
232
Timeout
Conflict
The plus reject time limit is
equal to or greater than the
maximum timeout value.
Change the +reject time limit
or maximum timeout value
through the Alarm Information
screen or Setup menu.
233
Timeout
Conflict
The minus suspect time
limit is equal to or greater
than the maximum timeout
value.
Change the +suspect time limit
or maximum timeout value
through the Alarm Information
screen or Setup menu.
234
Timeout
Conflict
The minus reject time limit
is equal to or greater than
the
maximum timeout value.
Change the - reject time limit
or maximum timeout value
through the Alarm Information
screen or Setup menu.
Table B.5 Setup Alarms and Messages, with Probable Cause and Corrective Action (Continued)
Alarm
ID
Display
Message
Alarm Condition/Cause Corrective Action
