Branson 2000Xc - Page 297

284 100-412-234 REV. 06
1 Afterburst_Amplitude AB Amplitude % 10 100
3 Afterburst_Delay AB Delay s 0.050 2.000
5 Afterburst_Time AB Time s 0.100 2.000
Act Clr Output
14 Act_Clear_Enable Act Clr Output N/A 0 1
13 Act_Clear_Dist Act Clr D in 0.1250 4.0000
13 Act_Clear_Dist Act Clr D mm 3.18 101.60
Cycle Aborts
44 Cycle_Abort_Enable Cycle Aborts N/A 0 1
71 Ground_Detect_Enable Gnd Det Abort N/A 0 1
78 Missing_Part_Enable Missing Part N/A 0 1
81 MissingPart_Min Minimum in 0.1250 4.0000
81 MissingPart_Min Minimum mm 3.18 101.60
82 MissingPart_Max Maximum in 0.1250 4.0000
82 MissingPart_Max Maximum mm 3.18 101.60
Pressure Limit
96 Pressure_Limit_Enable Pressure Limit N/A 0 1
94 Pressure_Limit_Minus - Pressure PSI 10 100
94 Pressure_Limit_Minus - Pressure kPa 69 689
95 Pressure_Limit_Plus + Pressure PSI 10 100
95 Pressure_Limit_Plus + Pressure kPa 69 689
Digital UPS
173
Clear_Mem_At_Reset_Enabl
e
Memory Reset N/A 0 1
207 Mem_Store_At_End Memory N/A 0 1
208 Timed_Seek Timed Seek N/A 0 1
Power Match Curve
165 PMC_Enable Pwr Match Curve N/A 0 1
161 PMC_High_Limit +R Band % 1 100
162 PMC_Low_Limit -R Band % 1 100
Weld Setup - Ext U/S Delay
58 Ext_Trigger_Delay Ext U/S Delay N/A 0 1
Weld Setup - Weld Mode
146 Weld_Mode Weld Mode N/A 0 5
145 Energy_Mode_Value Weld Energy J 1 45000
83 Peak_Power_Mode_Value Peak Power % 1.0% 100.0%
38 Collapse_Mode_Distance Collapse in 0.0004 1.0000
Table D.2 Parameter IDs
ID JSON Description Description Unit Min Value Max Value
