100-412-234 REV. 06 285
38 Collapse_Mode_Distance Collapse mm 0.01 25.40
8 Absolute_Mode_Dist, Absolute in 0.1250 4.0000
8 Absolute_Mode_Dist, Absolute mm 3.18 101.60
112 Scrub_Time_Enable Scrub Time Enable N/A 0 1
111 Scrub_Time Gnd Detect s 0.001 0.500
64 Frequency_Offset_Enable Frequency Offset N/A 0 1
113 Post_Weld_Seek_Enable Post Weld Seek N/A 0 1
Weld Setup - Weld Mode - Time
25 Auto_Scale_Enable (Graphs) Auto Scale N/A 0 1
Weld Setup - Weld Mode - Energy
48 Energy_Braking_Enable Energy Brake N/A 0 1
47 Energy_Brake_Time Energy Brake s 0.010 1.000
73 Weld_Pressure Weld Pressure PSI 10 100
73 Weld_Pressure Weld Pressure kPa 69 689
77 Max_Timeout Timeout s 0.050 30.000
72 Hold_Force Hold Force lb
Weld Setup - Weld Mode - Ground Detect
24 Scrub_Time_Amp Scrub Amp % 10 100
Setup Limits
233 ABSDIST_MLT - Absolute Distance in 0.1250 4.0000
233 ABSDIST_MLT - Absolute Distance mm 3.18 101.60
232 ABSDIST_PLT + Absolute Distance in 0.1250 4.0000
232 ABSDIST_PLT + Absolute Distance mm 3.18 101.60
221 AMPA_MLT - AMP A % 10 100
220 AMPA_PLT + AMP A % 10 100
231 COLLAPSEDIST_MLT - Collapse Distance in 0.0004 1.0000
231 COLLAPSEDIST_MLT - Collapse Distance mm 0.01 25.40
230 COLLAPSEDIST_PLT + Collapse Distance in 0.0004 1.0000
230 COLLAPSEDIST_PLT + Collapse Distance mm 0.01 25.40
236 SCRUBAMP_PLT + Scrub Amplitude % 10 100
237 SCRUBAMP_MLT - Scrub Amplitude % 10 100
215 DOWNSPEED_MLT - Down Speed % 1 100
214 DOWNSPEED_PLT + Down Speed % 1 100
217 HOLDPRESSURE_MLT - Hold Pressure PSI 10 100
217 HOLDPRESSURE_MLT - Hold Pressure kPa 69 689
216 HOLDPRESSURE_PLT + Hold Pressure PSI 10 100
216 HOLDPRESSURE_PLT + Hold Pressure kPa 69 689
Table D.2 Parameter IDs
ID JSON Description Description Unit Min Value Max Value
