286 100-412-234 REV. 06
219 HOLDTIME_MLT - Hold Time s 0.010 30.000
218 HOLDTIME_PLT + Hold Time s 0.010 30.000
229 PEAKPOWER_MLT - Peak Power % 1.0% 100.0%
228 PEAKPOWER_PLT + Peak Power % 1.0% 100.0%
235 SCRUBTIME_MLT - Scrub Time s 0.001 0.500
234 SCRUBTIME_PLT + Scrub Time s 0.001 0.500
239 TRIGDIST_MLT - Trigger Distance in 0.1250 4.0000
239 TRIGDIST_MLT - Trigger Distance mm 3.18 101.60
238 TRIGDIST_PLT + Trigger Distance in 0.1250 4.0000
238 TRIGDIST_PLT + Trigger Distance mm 3.18 101.60
223 TRIGFORCE_MLT - Trig Force lb 5 159
223 TRIGFORCE_MLT - Trig Force N 22 707
222 TRIGFORCE_PLT + Trig Force lb 5 159
222 TRIGFORCE_PLT + Trig Force N 22 707
227 WELDENERGY_MLT - Weld Energy J 1 45000
226 WELDENERGY_PLT + Weld Energy J 1 45000
213 WELDPRESSURE_MLT - Weld Pressure PSI 10 100
213 WELDPRESSURE_MLT - Weld Pressure kPa 69 689
212 WELDPRESSURE_PLT + Weld Pressure PSI 10 100
212 WELDPRESSURE_PLT + Weld Pressure kPa 69 689
225 WELDTIME_MLT - Weld Time s 0.010 30.000
224 WELDTIME_PLT + Weld Time s 0.010 30.000
Reject Limits
106 Reject_Limits_Enable Reject Limits N/A 0 1
108 Reject_Reset_Req_Enable Reset Required N/A 0 1
9 Absolute_MLR, Reject - -R Abs D in 0.1250 4.0000
11 Absolute_PLR, Reject + +R Abs D in 0.1250 4.0000
39 Col_MLR -R Col D in 0.0004 1.0000
39 Col_MLR -R Col D mm 0.01 25.40
41 Col_PLR +R Col D in 0.0004 1.0000
41 Col_PLR +R Col D mm 0.01 25.40
210 DOWNSPEEDMLR -R Downspeed in/s 0.3 7.0
210 DOWNSPEEDMLR -R Downspeed mm/s 8 178
209 DOWNSPEEDPLR +R Downspeed in/s 0.3 7.0
209 DOWNSPEEDPLR +R Downspeed mm/s 8 178
53 Energy_MLR -R Energy J 1 45000
56 Energy_PLR +R Energy J 1 45000
Table D.2 Parameter IDs
ID JSON Description Description Unit Min Value Max Value
