100-412-234 REV. 06 287
90 Peak_Power_MLR -R Pk Power % 1 100
92 Peak_Power_PLR +R Pk Power % 1 100
69 SBL_Frequency_Enable N/A N/A 0 1
68 SBL_Max_Frequency +R Freq Hz 29400 30600
67 SBL_Min_Frequency -R Freq Hz 29400 30600
118 Time_MLR -R Time s 0.010 30.000
120 Time_PLR +R Time s 0.010 30.000
123 Trigger_Distance_MLR -R Trg D in 0.1250 4.0000
123 Trigger_Distance_MLR -R Trg D mm 3.18 101.60
125 Trigger_Distance_PLR +R Trg D in 0.1250 4.0000
125 Trigger_Distance_PLR +R Trg D mm 3.18 101.60
149 Weld_Force_MLR -R Weld F lb 10 159
149 Weld_Force_MLR -R Weld F N 44 707
151 Weld_Force_PLR +R Weld F lb 10 159
151 Weld_Force_PLR +R Weld F N 44 707
Suspect Limits
115 Suspect_Limits_Enable Suspect Limits N/A 0.000 1.000
116 Suspect_Limits_Reset_Req Reset Required N/A 0 1
10 Absolute_MLS, Suspect - -S Abs D in 0.1250 4.0000
10 Absolute_MLS, Suspect - -S Abs D mm 3.18 101.60
12 Absolute_PLS, Suspect + +S Abs D in 0.1250 4.0000
12 Absolute_PLS, Suspect + +S Abs D mm 3.18 101.60
40 Col_MLS -S Col D in 0.0004 1.0000
40 Col_MLS -S Col D mm 0.01 25.40
42 Col_PLS +S Col D in 0.0004 1.0000
42 Col_PLS +S Col D mm 0.01 25.40
54 Energy_MLS -S Energy J 1 45000
57 Energy_PLS +S Energy J 1 45000
59 Frequency_MLR Frequency MLR
60 Frequency_MLS Frequency MLS
61 Frequency_PLR Frequency PLR
62 Frequency_PLS Frequency PLS
63 Frequency_Offset_Value Frequency Offset Hz 0 600
75 Hold_Time_Enable Hold Time Enable 0 1
203 Amp_Step_Distance_Val Amplitude Step Distance
204 Amp_Step_Force_Val Amplitude Step Force
91 Peak_Power_MLS -S Pk Power % 1.0 100.0
Table D.2 Parameter IDs
ID JSON Description Description Unit Min Value Max Value
