288 100-412-234 REV. 06
93 Peak_Power_PLS +S Pk Power % 1.0 100.0
119 Time_MLS -S Time s 0.010 30.000
121 Time_PLS +S Time s 0.010 30.000
124 Trigger_Distance_MLS -S Trg D in 0.1250 4.0000
124 Trigger_Distance_MLS -S Trg D mm 3.18 101.60
126 Trigger_Distance_PLS +S Trg D in 0.1250 4.0000
126 Trigger_Distance_PLS +S Trg D mm 3.18 101.60
150 Weld_Force_MLS -S Weld F lb 10 159
150 Weld_Force_MLS -S Weld F N 44 707
152 Weld_Force_PLS +S Weld F lb 10 159
152 Weld_Force_PLS +S Weld F N 44 707
Control Limits
85 Peak_Power_Cutoff_Enable Peak Power Cutoff N/A 0 1
43 Control_Limits_Enable Control Limits N/A 0 1
7 Abs_Cutoff_Flag Absolute Cutoff N/A 0 1
6 Abs_Cutoff_Distance Absolute Cutoff Distance in 0.1250 4.0000
6 Abs_Cutoff_Distance Absolute Cutoff Distance mm 3.18 101.60
37 Col_Cutoff_Distance ColCut in 0.0004 1.0000
37 Col_Cutoff_Distance ColCut mm 0.01 25.40
49
Energy_Compensation_Enab
le
Energy Comp N/A 0 1
52 Energy_Comp_ML Energy Min J 1 45000
55 Energy_Comp_PL Energy Max J 1 45000
84 Peak_Power_Cutoff Pk Pwr Cut % 1.0 100.0
36 Col_Cutoff_Enable ColCut N/A 0 1
Main Menu - System Configuration
32 Act_Assembly_Number Actuator Assembly N/A N/A N/A
33 PS_Assembly_Number P/S Assembly N/A N/A N/A
34 Stack_Assembly_Number Stack Assembly N/A N/A N/A
1140 Basic_Mode_Enable Basic Mode N/A 0 1
1141 Horn_Clamp_Enable Horn Clamp N/A 0 1
1142 UDI_Scan_Enable UDI Scan N/A 0 1
1143 Automation_Mode_Enable Automation Mode N/A 0 1
1144 Mem_Full_Continue_Enable Memory Full Continue N/A 0 1
1146 Authority_Check_Enable Authority Check N/A 0 1
1147 Barcode_Start_Char Barcode Start N/A 1 1
1148 Assembly_Num_Stack Assembly Number - Stack N/A 0 11
1149 Assembly_Num_Act Assembly Number - Actuator N/A 0 11
Table D.2 Parameter IDs
ID JSON Description Description Unit Min Value Max Value
To Next Page
