32 100-412-234 REV. 06
Reject Limits
User-definable limits at which the violating cycle is identified as
having produced a bad part.
Reset Required
State used with limits indicating that a reset will be required when
the limit is exceeded. The reset is accomplished by using the reset
key on the front of the power supply, or by external reset at the
User I/O.
Run Screen
The screen showing weld status, alarms, weld count, and process
information. Available using a front-panel button on the power
supply.
S-Beam Load Cell
Provides force measurement for accurate ultrasonic triggering and
graphing of force.
Scrub Time
In Ground Detect mode, the amount of time after detection of a
ground condition before the termination of ultrasonics, and end of
the cycle.
Seek
The activation of ultrasonics at a low-level (5%) amplitude, for the
purpose of finding the resonant frequency of the Stack.
Setup Limits
Minimum and maximum parameter changes allowed for a weld
preset.
Stack Converter, Booster, and Horn.
Start Frequency
The frequency stored in memory and the starting frequency of the
horn.
Step @ Col (in)
User-definable collapse distance at which AmpA is changed to
AmpB.
Step @ E (J) User-definable energy at which AmpA is changed to AmpB.
Step @ Ext Sig Allows you to step Amplitude based upon an external signal.
Step @ Pwr (%) User-definable power at which AmpA is changed to AmpB.
Step @ T (S) User-definable time at which AmpA is changed to AmpB.
Supervisor
Authority level below Executive. The Supervisor has access to all
configuration and weld setup features. Multiple Supervisor level
users can be created in the User ID table.
Suspect Limits
User-definable limits at which the resultant weld in a welding cycle
is identified as potentially bad (suspect).
SV Interlock SV Interlock input allows power supply to close an auxiliary door.
Sys Components
System Components. Assign names to the power supply, actuator,
and stack. Assigned names will become part of the system
configuration and weld preset.
Technician
Authority level below Supervisor. The supervisor can create and
save a weld setup, perform a horn down test, and run diagnostics.
The technician cannot validate, lock, or unlock a validated preset.
The technician cannot access the configuration menu. Multiple
Technician level users can be created in the User ID table.
Table 2.3 Glossary of Terms
Name Description
