Set up the Spectrum's plot options
See Spectrum | Display; or, in some browsers, the display controls are already open.
Select an Input by Name: (centered, above the spectral display). Click the Options
tab in the display controls. Set the plot options as desired; your changes are immediate.
Rename an Input
See MCA Settings | Inputs. Alphanumeric, 4 to 14 characters suggested.
Setting to Unlock a Locked Input
See Spectrum | Display. Depends on your Take Over setting.
To Enable the ability to Unlock an Input:
Setup | Security | <your User name>; Take Over button must be checked.
Save the CAM file of your acquisition (for use with Genie 2000, etc.)
•
See Spectrum | Save. Click the Save menu button.
• Right-Click on the here
link on the Save Input pop-up page.
• Select Save Target As... from the pull-down list (do NOT open the file).
• The Save As page will open. Select the storage drive location you wish.
• Edit the File name, changing it to something appropriate to describe your
Input, using the format <filename.cnf>. (This will be your CAM file when
done).
• Click Save to write the new CAM file to the desired location.
Change Input Definition
First, select the Input Name from the list at the top-center of the spectrum display.
Then, go to MCA Settings | Inputs. Choose the Acquisition Mode from the list.
Set Input type and typical Definition information
See MCA Settings | Acq Setup. Only parameters for your type of Input are offered.
Set Presets
See MCA Settings | Acq Setup. Only supported presets will be offered.
Set External Start/Stop options
See MCA Settings | Acq Setup. Supported options are presented.
Digital Oscilloscope
Best if used with Internet Explorer or Opera, or a Java compliant browser. Chapter 5
of this User's Guide is dedicated to this feature.
User’s Manual 7
FAQ & Common Events
