225 • DM NAX® Product Manual — Doc. 9045M
have a corresponding line-level output. The Line Out Volume is only applied when Line Out EQ Bypass is
enabled.
1. To set the line out volume, do one of the following:
l
Move the Line Out Volume slider to the right to increase or to the left to decrease the line
out volume.
l
Click the arrows to increase or decrease the line out volume. Values range from 0 to 100,
adjustable in increments of 1. This range in dB is -80dB to 20dB.
l
Manually enter a value in the Line Out Volume field.
2. Set the Line Out EQ Bypass toggle to the right position to have the line-level output signal bypass
the zone's equalizer settings. Set the toggle to the left position to have the line-level output signal
pass through the zone's equalizer. By default, Line Out EQ Bypass is disabled.
NOTE: When the Line Out EQ Bypass setting is disabled, the line-level output's level will
mirror the speaker output's Zone volume control. This allows for a variable signal level in
applications where the line-level output is connected to an uncontrolled device such as
powered speakers. If the Line Out EQ Bypass setting is enabled, the Line Out Volume slider
can be used to set a fixed level for the line-level output. This level will not be affected by the
speaker output Zone volume controls, so this configuration is better suited to applications
where the line output is connected to a controlled amplifier with its own level adjustment.
