Product Manual — Doc. 9045M DM NAX® • 344
2. Set the Line Out EQ Bypass toggle to the right position to have the line-level output signal bypass
the zone's equalizer settings. Set the toggle to the left position to have the line-level output signal
pass through the zone's equalizer. By default, Line Out EQ Bypass is disabled.
NOTE: When the Line Out EQ Bypass setting is disabled, the line-level output's level will
follow the speaker output's Zone volume control. This allows for a variable line-level output in
applications where the line-level output is connected to an uncontrolled device such as
powered speakers. If the Line Out EQ Bypass setting is enabled, the Line Out Volume slider
can be used to set a fixed level for the line-level output. This level will not be affected by the
speaker output Zone volume controls, which is better suited to applications where the line
output is connected to a controlled amplifier with its own level adjustment.
