Product Manual — Doc. 9045M DM NAX® • 49
Controls and Indicators
PWR (1) LED. Amber indicates that the device is booting. White indicates that the device is
switched on with audio passing. Red indicates that the device is in standby mode. Off
indicates that there is no power from the power supply.
LAN (1) LED. White indicates that the device is switched on and has a valid IP address. Off
indicates that the device is not connected to a network or the IP address is invalid.
NAX (1) LED. White indicates that AoIP is ready to pass and the unit's PTP clock is synced.
Off indicates that no AoIP is passing to or from and/or PTP is not synced.
SOURCE 1-16 (16) LEDs. White indicates signal presence on the specified input/source. Red
indicates there is a clipping on an analog input or a bitstream issue on a digital input.
Off indicates that there is no signal detected on the specified input/source.
SETUP (1) LED. Blinking red indicates that a network reset or factory restore has been
initiated via the adjacent SETUP button.
Power
Power Consumption 20 Watts
Environmental
Temperature 32° to 104°F (0° to 40°C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 70 BTU/hr
Construction
Chassis Metal, black and silver finish, vented sides
Mounting 1 RU rack-mountable
Dimensions
Height 1.25 in. (32 mm)
Width 19 in. (483 mm);
17.28 in. (439 mm) without rack ears
Depth 14.46 in. (368 mm)
Weight
7.39 lb (3.35 kg)
Compliance
Regulatory Model: M1845004
FCC Part 15 Class B digital device, CE, ETL listed
