3.11 Simultaneously Scanning Different Size Documents - Mixed Size Originals
347
3
User Friendly Features
Basic Copying Added Features Image Quality Others
Procedure
1
Align all of the documents so that the
A and B sides of all documents are
flush against the top left corner.
Remove any clips or staples attached to documents.
Make sure that the documents are flush against the top
left corner. Otherwise, copies might not be made prop-
erly.
The A side of the document refers the direction of the
document towards the inner side of the machine.
2
Load all documents so that they are
aligned with the top left corner of the
DADF, and align the document guide.
For details about loading documents, see “2.1 Loading
Paper” (P. 28) in “Part 1 Hardware”.
Be sure to load the B side of the document aligned with
the inner side of the DADF. Otherwise, this may cause
document jams.
A
B
Align documents to
this corner
■How to Load Different Size Documents
Load different size documents so that they are aligned with the top left corner as shown below:
Set documents to Head to Top
and align to top left corner.
Load portrait and landscape documents of B4 in size
together as landscape documents and align to top
left corner.
A
B
Report
1
A
B
Report
1
To Next Page
