Fuji Xerox DocumentCentre C400 Series User Manual

1.2 Loading Documents
273
Loading Documents
1
1.2.3 About Orientation When Loading Docu-
ments
This machine has a feature for shifting the top, bottom, left, and right positions of
documents like the Margin Shift feature. If the document is not loaded at the cor-
rect orientation (text orientation), the document will not be copied correctly.
Specify the document orientation at Original Orientation. By specifying the orien-
tation of text in the document, the machine judges the top, bottom, left and right
sides of the document, and makes copies of the document shifted to the preset
position.
Original Orientation is provided with two settings Head to Top and Head to Left.
Default is Head to Top. So, load the document in the direction that text can be
read. If the document cannot be loaded in the Head to Top, specify Head to Left
under Original Orientation in the Added Features screen.
For details about the document orientation, see “3.31 Specifying the Document Orientation - Origi-
nal Orientation” (P. 417).
Document placed on document glass
ttnnn
Top
Bottom
Left Right
Document placed on document glass
Top
Bottom
Left Right
When <U>Head to Top<U> is set When <U>Head to Left<U> is s
e
Document loaded on DADFDocument loaded on DADF
When Head to Top is set When Head to Left is set
