Chapter 2 Troubleshooting
2.3 Error Code FIP
2-68
FIP1.22 077-312 Tray Configure Error
Step Check and Action Yes No
Parts considered to be the cause
PWB ASSY OPT TRAY (PL10.1.5)
PWBA MCU (PL18.2.2)
HARNESS ASSY OP FDR (PL18.3.8)
HARNESS ASSY FDR DRAWER 1 (PL10.1.18)
1
Check the Tray configuration
Does the Tray configuration suit the specification?
Go to Step 2.
Change the
Tray configura-
tion related to
the specifica-
tion
2
Check connector connection
Check the connections between the PWB ASSY OPT TRAY
and the PWBA MCU, as well as between the PWB ASSY OPT
TRAY and the PWB LVPS.
Are the HARNESS ASSY OP FDR (P/J213-P/J243, P/J24-P/
J243) and the HARNESS ASSY FDR DRAWER 1
(P/J243-P/J419) connected securely?
Go to Step 3.
Securely con-
nect the HAR-
NESS ASSY
OP FDR (P/
J213-P/J243,
P/J24-P/J243)
and the HAR-
NESS ASSY
FDR DRAWER
1
(P/J243-P/
J419)
3
Check after replacing the HARNESS ASSY OP FDR
Replace the HARNESS ASSY OP FDR.
Does an error occur?
Go to Step 4. End of work.
4
Check after replacing the HARNESS ASSY FDR DRAWER 1
Replace the HARNESS ASSY FDR DRAWER 1.
Does an error occur?
Go to Step 5. End of work.
5
Check after replacing the PWB ASSY OPT TRAY
Replace the PWB ASSY OPT TRAY. (REP 10.3)
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
To Next Page
