Chapter 5 Parts List
PL 10.1 Option Feeder (1/3) [List]
ITEM PARTS No. DESCRIPTION A.C
1 059K 75820 FEEDER ASSY OPT 250 (with 2, 5, 7-11, 13-20, 26-28) 50AA
2 848E 83651 COVER-SIDE L OPT 250 MAT 32CB
3--
4--
5 960K 64970 (SCC) PWBA ASSY OPÇs TRAY 5023
6--
7 007K 18290 (SCC) DRIVE ASSY OPT 250 (with 19) 5090
8 005K 83210 CLUTCH ASSY OPT FEED 5092
9 807E 39530 GEAR-OPT IDLER 250 5093
10 807E 38250 GEAR-OPT FEEDER 250 509B
11 -- HARNESS ASSY TRAY MOT 71BB
12 --
13 848E 83720 COVER-SIDE R OPT 250 AIO MAT 32CC
14 -- FOOT 31CD
15 050K 69100
TRAY ASSY 250 IOT (PL 10.3)
50BB
16 848E 83761 COVER-LIP TOP OPT MAT 32CE
17 848E 83750 COVER-REAR OPT 250 MAT 32CF
18 952K 04650 (SCC) HARNESS ASSY FDR DRAWER 1 71BC
19 -- (SCC) MOTOR-ASSY OPTION 5091
20 059K 74290 (SCC) FEEDER ASSY-OPT 250 MAIN (PL 10.2) 5030
21 --
22 --
23 --
24 --
25 --
26 -- SCREW LOCK 31CG
27 803E 12080 LOCK TRAY 31CH
28 -- BEARING NUDGER 509C
97 604K 77650
KIT FOOT ASSY (with 14*3 pcs)
31CJ
98 604K 77640
KIT SCREW LOCK (with 26*2 pcs)
31CK
To Next Page
