Chapter 6 General
6.6 IOT Diag
6-56
6.6.6 ATC Mode
Sets whether to enable the ATC (Automatic Toner Control) empty detection mode.
ON: Changes the toner cartridge detection method to the count method.
OFF: Changes the toner cartridge detection method to the ATC method.
Procedure
1 Enter the CE mode. (See "6.4.2 How to Enter the CE Mode".)
2 Confirm that [Printer Diag] is selected, and then press the [OK] button.
3 Use the [T] button to select [IOT Diag], and then press the [OK] button.
4 Use the [T] button to select [ATC Mode], and then press the [OK] button.
5 Use the [S] or [T] button to change the ON/OFF setting, and then press the [OK] button for con-
firmation.
6 Press the [C(Clear)] button to return to the [Printer Diag] screen.
7 Exits the CE mode. (See "6.4.4 How to Exit the CE Mode".)
Printer Diag
IOT Diag
IOT Diag
Digital Input
IOT Diag
ATC Mode
ATC Mode
OFF*
To Next Page
