Chapter 2 Troubleshooting
2.3 Error Code FIP
2-47
FIP1.3 005-301 DADF Cover Open
Step Check and Action Yes No
Parts considered to be the cause
DADF ASSY (PL21.1.1)
PWBA ESS (PL18.1.2)
1
Check the DADF Cover
Is the DADF Cover closed properly?
Go to Step 2.
Close the DADF
Cover properly
2
Check connector connection
Check the connection between the DADF ASSY and
the PWBA ESS.
Is the P/J453 connected securely?
Go to Step 3.
Connect P/J453
securely
3
Check after replacing the DADF ASSY
Replace the DADF ASSY. (REP 21.1)
Does an error occur?
Replace the
PWBA ESS.
(REP18.1)
End of work.
To Next Page
