Chapter 6 General
6.5 ESS Diag
6-41
To exit the test mode, restart the printer.
6.5.8.2 Single Step
Single Step allows you to collect Device Descriptor from the device of the specified address in a single step.
Procedure
1 Enter the CE mode. (See "6.4.2 How to Enter the CE Mode".)
2 Confirm that [Printer Diag] is selected, and then press the [OK] button.
3 Confirm that [ESS Diag] is selected, and then press the [OK] button.
4 Use the [T] button to select [USB Host Test], and then select the [OK] button.
5 Use the [T] button to select [Single Step], and then press the [OK] button.
6 Specify the device address. (Available addresses are 0 through 127.)
• Use the [W] or [X] button to move the cursor to left or right.
Table 6-37 Test Mode (when a USB storage device is inserted in the Front USB Port)
Item Description
TEST MODE
TEST J Keeps the DownStream port of the Host Controller in the J state.
TEST K Keeps the DownStream port of the Host Controller in the K state.
TEST SE0 Keeps the DownStream port of the Host Controller in the SE0 state.
TEST PACKET
Repeatedly sends the test packet form the DownStream port of the
Host Controller
TEST ENABLE
Forcefully changes the DownStream port of the Host Controller to
[ENABLE].
ESS Diag
All Test
Printer Diag
ESS Diag
ESS Diag
USB Host Test
USB Host Test
TEST MODE
USB Host Test
Single Step
Single Step
Address: 000
To Next Page
