Chapter 6 General
6.11 Board Diag (Board Test)
6-73
6.11 Board Diag (Board Test)
This section describes the details of the Board Diag.
6.11.1 All Test
Continually performs the Fax Memory, Fax Card I/F, AFE Serial I/F, IIT I/F, and ASIC tests.
6.11.2 Fax Memory Test
Performs the read/write check (Fax Flash W/R Test / SRAM W/R Test) of the Fax memory.
6.11.3 I/F Test
I/F Test provides the communication test between Fax Card, AFE Serial I/F, and IIT (Fax Card I/F Test, AFE
Serial I/F Test, and IIT I/F Test).
Table 6-45 All Test
Test Result Display
Remarks
Normal Error
CHECK OK *** Test Check NG
***: Displays the name of the test ended in error.
Fax Flash W/R / SRAM W/R / Fax Card I/F / AFE Serial I/F /
IIT I/F/ ASIC IJAC / ASIC JBIG
Table 6-46 All Test
Test Result Display
Remarks
Normal Error
CHECK OK *** Test Check NG
***: Displays the name of the test ended in error.
Fax Flash W/R / SRAM W/R
Table 6-47 All Test
Test Result Display
Remarks
Normal Error
CHECK OK *** Test Check NG
***: Displays the name of the test ended in error.
Fax Card I/F / AFE Serial I/F / IIT I/F
To Next Page
