Chapter 2 Troubleshooting
2.3 Error Code FIP
2-64
FIP1.18 075-100 MSI Misfeed Jam
Step Check and Action Yes No
Parts considered to be the cause
MSI Feed Roll / Nudger Roll [HOLDER ASSY PICK UP]
(PL13.1.15)
KIT RETARD ROLL MSI ASSY(PL13.2.98)
Regi. Sensor [HVPS] (PL18.2.5)
SOLENOID FEED MSI (PL13.1.5)
DRIVE ASSY MAIN (PL3.1.1)
PWBA MCU (PL18.2.2)
1
Check the paper transport path
Is there any foreign substances or bits of paper found on
the paper transport path?
Remove the
foreign sub-
stances and
bits of paper,
etc.
Go to Step 2.
2
Check the paper feed rolls
Are the paper feed rolls (the rolls that are listed among the
parts considered to be the cause) installed properly?
Go to Step 3.
Reinstall the
corresponding
paper feed rolls
3
Check the paper feed rolls
Are the paper feed rolls (the rolls that are listed among the
parts considered to be the cause in sequence) deformed or
worn out?
Replace the
corresponding
paper feed rolls
Go to Step 4.
4
Check the Regi. Sensor [HVPS] operation
Execute the Diag Digital Input [071-102] to check the oper-
ation of the Regi. Sensor [HVPS].
Is the Regi. Sensor [HVPS] operating normally?
Go to Step 5. Go to FIP2.2
5
Check the operation of the SOLENOID FEED MSI
Execute the Diag Digital Output [071-004] to check the
operation of the SOLENOID FEED MSI.
Is the SOLENOID FEED MSI operating normally?
Go to Step 6. Go to FIP2.11
6
Check the operation of the DRIVE ASSY MAIN
Execute the Diag Digital Output [071-001] to check the
rotation of the DRIVE ASSY MAIN.
Is it working properly?
Replace the
PWBA MCU.
(REP 18.2)
Go to FIP2.12
To Next Page
