Fuji Xerox DocuPrint M355df User Manual

Chapter 2 Troubleshooting
2.3 Error Code FIP
2-79
FIP2.6 CLUTCH ASSY EXIT (PL3.1.6)
Step Check and Action Yes No
Parts considered to be the cause
HOLDER ASSY DRIVE EXIT OUT (PL3.1.2)
HOLDER ASSY DRIVE EXIT IN (PL3.1.3)
CLUTCH ASSY EXIT (PL3.1.6)
PWBA MCU (PL18.2.2)
1
Check for foreign substances in the CLUTCH ASSY EXIT
Drive Section
Are there any foreign substances in the CLUTCH ASSY
EXIT Drive Section?
Remove the
foreign sub-
stances
Go to Step 2.
2
Check the shape of the HOLDER ASSY DRIVE EXIT OUT
and the HOLDER ASSY DRIVE EXIT IN
Is the HOLDER ASSY DRIVE EXIT OUT or the HOLDER
ASSY DRIVE EXIT IN damaged?
Replace the
HOLDER
ASSY DRIVE
EXIT OUT and
the HOLDER
ASSY DRIVE
EXIT IN
Go to Step 3.
3
Check connector connection
Check the connection between the CLUTCH ASSY EXIT
and the PWBA MCU.
Is the CLUTCH ASSY EXIT (P/J16) connected securely?
Go to Step 4.
Securely con-
nect the
CLUTCH
ASSY EXIT
(P/J16)
4
Check after replacing the CLUTCH ASSY EXIT
Replace the CLUTCH ASSY EXIT. (REP 3.2)
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
