Chapter 6 General
6.1 Specifications
6-5
6.1.4 Power Consumption
The following table represents the power consumption of each operation mode under rated input voltage
(110, 127, 220VAC).
6.1.5 Rush Current
When the power switch is turned on, the inrush current shall be maximum 50Amp (Cold start)/135Amp (Hot
start) at first 2.5msec, and 80Amp (110V/220V/240V) within 10msec.
6.1.6 Dimensions/Weight
*1: Measured with the MSI cover closed.
*2: Measured with the output tray extension closed.
*3: Includes the protrusions of the Rear Fan on the Rear Cover.
*4: Includes consumables (Toner Cartridge and Drum Cartridge) but not options, power cord, or media.
Allowance: Size= +/-1%, Weight= +/-1% kg (Uniformed to +/- 0.1 kg if 10 kg or less)
6.1.7 Dimensions and Weight of Optional Tray
Table 6-5
Operation Mode DocuPrint M355 df
Sleep Mode 4.5Wh/h (Ave.) or less
Low Power Mode 11Wh/h (Ave.) or less
Ready Mode 65Wh/h (Ave.) or less
Running Mode 500Wh/h (Ave.) or less
Maximum Power
Consumption
1200W (Max) or less
Table 6-6
Product Name Width (mm)
Depth (mm)
*3
Height (mm)
Weight (kg)
*4
DocuPrint M355 df (MFP Model)
*1, *2
430 426 503 18.1
Table 6-7
Optional Tray Width (mm) Depth (mm)
Height (mm)
*1
Weight (kg)
250 Sheet Feeder (MFP Model) 430 399 90 2.56
