Chapter 2 Troubleshooting
2.3 Error Code FIP
2-45
2.3 Error Code FIP
2.3.1 Level 1 FIP
FIP1.1 004-310 IOT Option Feeder I/F Failure
Step Check and Action Yes No
Parts considered to be the cause
PWB ASSY OPT TRAY (PL10.1.5)
PWBA MCU (PL18.2.2)
HARNESS ASSY OP FDR (PL18.3.8)
HARNESS ASSY FDR DRAWER 1 (PL10.1.18)
1
Check connector connection
Check the connections between the PWB ASSY OPT
TRAY and the PWBA MCU, as well as between the
PWB ASSY OPT TRAY and the PWB LVPS.
Are the HARNESS ASSY OP FDR (P/J213-P/J243,
P/J24-P/J243) and the HARNESS ASSY FDR
DRAWER 1 (P/J243-P/J419) connected securely?
Go to Step 2.
Securely connect the
HARNESS ASSY OP
FDR
(P/J213-P/J243,
P/J24-P/J243) and the
HARNESS ASSY FDR
DRAWER 1
(P/J243-P/J419)
2
Check after replacing the HARNESS ASSY OP FDR
Replace the HARNESS ASSY OP FDR.
Does an error occur?
Go to Step 3. End of work.
3
Check after replacing the HARNESS ASSY FDR
DRAWER 1
Replace the HARNESS ASSY FDR DRAWER 1.
Does an error occur?
Go to Step 4. End of work.
4
Check after replacing the PWB ASSY OPT TRAY
Replace the PWB ASSY OPT TRAY. (REP 10.3)
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
