Chapter 2 Troubleshooting
2.3 Error Code FIP
2-65
FIP1.19 077-104 Regi. Off Jam
Step Check and Action Yes No
Parts considered to be the cause
ROLL ASSY RUBBER (PL15.2.6)
ROLL ASSY REGI PINCH (PL15.2.8)
ROLL REGI PINCH (PL15.2.37)
Transfer Unit [ROLL ASSY-TRANS CRU] (PL6.1.1)
Drum Cartridge [XERO ASSY] (PL8.1.1)
Regi. Sensor [HVPS] (PL18.2.5)
REGI. CLUTCH (PL15.2.4)
DRIVE ASSY MAIN (PL3.1.1)
PWBA MCU (PL18.2.2)
1
Check the paper transport path
Is there any foreign substances or bits of paper found on
the paper transport path?
Remove the
foreign sub-
stances and
bits of paper,
etc.
Go to Step 2.
2
Check the paper feed rolls
Are the paper feed rolls (the rolls that are listed among the
parts considered to be the cause) installed properly?
Go to Step 3.
Reinstall the
corresponding
paper feed
rolls
3
Check the paper feed rolls
Are the paper feed rolls (the rolls that are listed among the
parts considered to be the cause in sequence) deformed or
worn out?
Replace the
corresponding
paper feed
rolls
Go to Step 4.
4
Check the Regi. Sensor [HVPS] operation
Execute the Diag Digital Input [071-102] to check the oper-
ation of the Regi. Sensor [HVPS].
Is the Regi. Sensor [HVPS] operating normally?
Go to Step 5. Go to FIP2.2
5
Check the REGI. CLUTCH operation
Execute the Diag Digital Output [071-006] to check the
operation of the REGI. CLUTCH.
Is the REGI. CLUTCH operating normally?
Go to Step 6. Go to FIP2.8
6
Check the operation of the DRIVE ASSY MAIN
Execute the Diag Digital Output [071-001] to check the
rotation of the DRIVE ASSY MAIN.
Is it working properly?
Replace the
PWBA MCU.
(REP 18.2)
Go to FIP2.12
To Next Page
