Chapter 2 Troubleshooting
2.3 Error Code FIP
2-83
FIP2.10 CLUTCH ASSY OPT FEED (PL10.1.8) (Option)
Step Check and Action Yes No
Parts considered to be the cause
GEAR-OPT IDLER 250 (PL10.1.9)
GEAR-OPT FEEDER 250 (PL10.1.10)
CLUTCH ASSY OPT FEED (PL10.1.8)
HARNESS ASSY OP L COMP (PL10.2.3)
PWBA ASSY OPT TRAY (PL10.1.5)
1
Check for foreign substances in the CLUTCH ASSY OPT
FEED Drive Section
Are there any foreign substances in the CLUTCH ASSY
OPT FEED Drive Section?
Remove the
foreign sub-
stances
Go to Step 2.
2
Check the shape of the GEAR-OPT IDLER 250 and the
GEAR-OPT FEEDER 250
Is the GEAR-OPT IDLER 250 or the GEAR-OPT
FEEDER 250 damaged?
Replace the
GEAR-OPT
IDLER 250
and the
GEAR-OPT
FEEDER 250
Go to Step 3.
3
Check connector connection
Check the connection between the CLUTCH ASSY OPT
FEED and the PWBA ASSY OPT TRAY.
Is the HARNESS ASSY OP L COMP (P/J4201-P/J420)
connected securely?
Go to Step 4.
Securely con-
nect the HAR-
NESS ASSY OP
L COMP
(P/J4201-P/
J420)
4
Check after replacing the CLUTCH ASSY OPT FEED
Replace the CLUTCH ASSY OPT FEED. (REP 10.9)
Does an error occur?
Go to Step 5. End of work.
5
Check after replacing the HARNESS ASSY OP L COMP
Replace the HARNESS ASSY OP L COMP.
Does an error occur?
Replace the
PWBA ASSY
OPT TRAY
(REP 10.3)
End of work.
To Next Page
