Chapter 6 General
6.13 Scanner Maintenance
6-81
6.13.6 Vertical Scan Mag.
Sets the parameters of the magnification for the slow scanning direction.
6.13.7 Test Pattern
Sets the parameter for the test pattern.
6.13.8 IIT I/O Check
Checks the operation of the IIT I/O components.
Table 6-55 Registration Parameters
Item Range Description
Mag FB COLOR
2 digits (hexadecimal)
(each digit 0-9, A-F)
Displays or changes the parameter value of each
item of the magnification for the slow scanning
direction.
Mag FB GRAY
Mag DADF COLOR
Mag DADF GRAY
Table 6-56 Test Patterns
Item Range Description
Pattern No. 3 digits (each digit 0-9)
Displays or changes the parameter value of each
item of the test pattern.
Pt07: Step Cycle
4 digits (hexadecimal)
(each digit 0-9, A-F)
Pt08: Step Cycle
Table 6-57 IIT Input Check
Item Sensor Status Description
Home Pos Sensor
ON or OFF
Displays the status of each Sensor as ON or
OFF.
Tray Sensor
Feed Sensor
DADF Cover Sensor
DADF Duplex Sensor
