Chapter 2 Troubleshooting
2.4 Other FIP
2-88
2.4 Other FIP
2.4.1 Abnormal Noise
FIP-N1 Abnormal Noise: When Power is Turned On
Step Check and Action Yes No
Parts considered to be the cause
TONER CARTRIDGE (PL8.1.2)
MOTOR DISP (PL5.1.9)
DRIVE ASSY MAIN (PL3.1.1)
1
Check the MOTOR DISP operation
Execute the Diag Digital Output [093-001] to check the
rotation of the MOTOR DISP.
Is there any abnormal noise from the device?
Stop the motor operation within three seconds.If the
motor operation is continued for three seconds or longer,
the device will be damaged.
Go to Step 2. Go to Step 3.
2
Check the installation of the TONER CARTRIDGE
Reinstall the TONER CARTRIDGE.
Turn the power OFF and ON.Does an abnormal noise
occur?
Replace the
TONER CAR-
TRIDGE
If the problem
cannot be
solved,
replace the
printer.
End of work.
3
Check the operation of the DRIVE ASSY MAIN
Execute the Diag Digital Output [071-001] to check the
rotation of the DRIVE ASSY MAIN.
Is there any abnormal noise from the device?
Stop the motor operation within three seconds.If the
motor operation is continued for three seconds or longer,
the device will be damaged.
Replace the
DRIVE ASSY
MAIN (REP
3.1)
End of work.
To Next Page
