Chapter 2 Troubleshooting
2.3 Error Code FIP
2-61
FIP1.15 062-311/ 062-320 / 062-321 / 062-322 / 062-360 / 062-371 /
062-393 Scanner Error
Step Check and Action Yes No
Parts considered to be the cause
IIT ASSY (PL21.1.14)
PWBA ESS (PL18.1.2)
1
Check connector connection
Check the connection between the IIT ASSY and the
PWBA ESS.
Are the P/J451 and the P/J452 connected securely?
Go to Step 2.
Connect the P/
J451 and the P/
J452 securely
2
Check after replacing the IIT ASSY
Replace the IIT ASSY. (REP 21.1)
Does an error occur?
Replace the
PWBA ESS.
(REP18.1)
End of work.
To Next Page
