Chapter 6 General
6.6 IOT Diag
6-53
6.6.3.3 NVM Loading (Load NVM from ESS)
Loads the information saved in the ESS NVM to the IOT NVM.
If [Save NVM to ESS] has never been executed, [Load NVM from ESS] is not displayed.
Procedure
1 Enter the CE mode. (See "6.4.2 How to Enter the CE Mode".)
2 Confirm that [Printer Diag] is selected, and then press the [OK] button.
3 Use the [T] button to select [IOT Diag], and then press the [OK] button.
4 Use the [T] button to select [NVM Settings], and then press the [OK] button.
5 Use the [T] button to select [Load NVM from ESS], and then press the [OK] button.
6 Press the [OK] button.
7 Press the [C(Clear)] to return to the [Printer Diag] screen, and then exit the CE mode.
(See "6.4.4 How to Exit the CE Mode".)
Printer Diag
IOT Diag
IOT Diag
Digital Input
IOT Diag
NVM Settings
NVM Settings
Edit NVM
NVM Settings
Load NVM from ESS
Load NVM from ESS
OK?
Load NVM from ESS
Processing
Load NVM from ESS
Loaded
To Next Page
Loading...
