5 – 30
Chapter 5 Parts List
PL 13.2 MSI (2/2) [List]
ITEM PARTS No. DESCRIPTION A.C
1 -- TRAY BASE MSI 5110
2 032E 39890 GUIDE END MSI 5111
3 -- COVER MSI 5112
4 019E 83831 HOLDER-END MSI 5113
5--PAD MSI 5114
6 -- GUIDE-SIDE MSI L MAT 5115
7 -- GUIDE-SIDE MSI R MAT 5116
8 -- LABEL-PAPER SET MSI 5117
9 050K 69900 TRAY ASSY MSI (with 1-8, 10-20) 5118
10 -- SPRING-RETARD ROLL 5119
11 -- SPRING-STOPPER SHEET 150 511B
12 -- LOCK-SHEET 150 511C
13 -- GUIDE-RETARD MSI MYLAR 511D
14 -- STOPPER-SHEET 150 511E
15 -- HOLDER-RETARD ROLL MAT 511F
16 -- ROLL ASSY-RETARD ROLL 5233
17 -- CLUTCH ASSY FRICTION 511H
18 -- SPRING-MSI PAPER STOPPER MID 511J
19 -- RACK GUIDE SIDE 511K
20 -- GEAR PINION 511L
96 604K 77430 KIT MSI FRAME ASSY (with 1, 2, 4, 5, 19, 20) 511M
98 604K 78370
KIT RETARD ROLL MSI ASSY (with 10-15, 27)
511N
99 --
KIT MSI COVER (with 3, 8)
511P
To Next Page
