5 – 28
Chapter 5 Parts List
PL 13.1 MSI (1/2) [List]
ITEM PARTS No. DESCRIPTION A.C
1 -- STOPPER MSI IN 51BB
2 -- LOCK MSI IN 51BC
3 -- FRAME TOP MSI 32DB
4 -- ACTUATOR NO PAPER MSI 51BD
5 -- (SCC) SOLENOID FEED MSI 51BE
6 -- GEAR SEGMENT MSI 1 51BF
7 -- GEAR SEGMENT MSI 2 51BG
8 -- BEARING FEED MSI 51BH
9 031E 98882 ARM LIFTER MSI 51BJ
10 803E 12144 STOPPER LIFTER MSI 51BK
11 809E 98910 SPRING FEED MSI 51BL
12 -- GEAR FEED MSI 51BM
13 011E 27090 LEVER LIFTER MSI 51BN
14 809E 98900 SPRING NF MSI 51BP
15 059K 78790 HOLDER ASSY PICK UP (with 16-20) 5130
16 -- HOLDER PICK UP 513B
17 -- GEAR IDLER FEEDER 513C
18 -- ROLL ASSY FEED (with 19, 20) 5132
19 -- ROLL RUBBER 513B
20 -- CORE ROLL MAT 513F
21 -- SHAFT FEED MSI 513G
22 -- BEARING FEED MSI 513H
23 005E 33030 FLANGE PICK UP 51BQ
95 604K 77460 KIT MSIÃ…@SOLENOIDÃ…@ASSY (with 5-7) 51BR
97 801K 52620
FRAME ASSY-TOP MSI (with 1-4)
513J
To Next Page
