Chapter 2 Troubleshooting
2.3 Error Code FIP
2-52
FIP1.8 042-313 LVPS Fan Motor Failure
Step Check and Action Yes No
Parts considered to be the cause
LVPS FAN (PL4.1.1)
HARNESS ASSY LV (PL18.3.5)
PWB LVPS (PL18.1.5)
PWBA MCU (PL18.2.2)
1
Check the LVPS FAN operation
Execute the Diag Digital Output [042-003] to check the
rotation of the LVPS FAN.
Is it working properly?
Replace the
PWBA MCU.
(REP 18.2)
Go to Step 2.
2
Check the installation of the LVPS FAN
Manually rotate the LVPS FAN.Is there any loading?
Reinstall the LVPS
FAN properly
Go to Step 3.
3
Check connector connection
Check the connection between the LVPS FAN and
LVPS, as well as between the PWB LVPS and PWBA
MCU.
Are the LVPS FAN (P/J241) and the HARNESS ASSY
LV (P/J220-P/J22) connected securely?
Go to Step 4.
Securely connect
the LVPS FAN
(P/J241) and the
HARNESS ASSY
LV
(P/J220-P/J22)
4
Check after replacing the LVPS FAN
Replace the LVPS FAN.
Does an error occur?
Go to Step 5. End of work.
5
Check after replacing the HARNESS ASSY LV
Replace the HARNESS ASSY LV.
Does an error occur?
Go to Step 6. End of work.
6
Check after replacing the PWB LVPS
Replace the PWB LVPS. (REP 18.4)
Does an error occur?
Replace the
PWBA MCU. (REP
18.2)
End of work.
