5 – 24
Chapter 5 Parts List
PL 10.2 Option Feeder (2/3) [List]
ITEM PARTS No. DESCRIPTION A.C
1 -- COVER-SENSOR NO PAPER 250 32DB
2 930W 00123 SENSOR PHOTO (NO PAPER SENSOR) 50CB
3 -- HARNESS ASSY OP L COMP 71CB
4 -- CHUTE-UPPER OPT 250 50DC
5 -- BEARING NUDGER 50CC
6 -- SUPPORT ASSY NUDGER 50DD
7 -- (SCC) CLUTCH ONEWAY FEED 50CD
8 -- GEAR FEED 50CE
9 -- BEARING NUDGER 50CF
10 -- GEAR IDLER NUDGER 50CG
11 -- ACTUATOR NO PAPER 50CH
12 -- SHAFT NUDGER 50CJ
13 -- ROLL ASSY FEED 5042
14 -- GEAR NUDGER 50CK
15 -- CHUTE-LOWER OPT 250 50DE
16 -- SHAFT ASSY-FEED 250 50CL
17 -- ROLL SUPPORT 50CM
18 -- BRACKET NUDGER AD OPT 50DF
99
604K 11192 KIT ROLL ASSY FEED (with 13*3 pcs) 503C
To Next Page
