Chapter 4 Disassembly / Assembly and Adjustment
4.3 Adjustment
4-138
4.3 Adjustment
REP18 Elec
REP18.1 Directions for Replacing Important Information
Stored Component
[Purpose]
To get a full understanding of how to handle Important Information Stored Components. Data that the customer has
entered after machine installation is so important that nobody can be forgiven for a loss or leak of the data. Besides, from
the perspective of earning the confidence of the customer, it is indispensable for the CE to be able to realize the compo-
nents that store such data. The CE should also take great care in replacing such components.
[Procedure]
This product has the components below store important information. Perform the following procedure.
IBG）Collect/discard components, following the way specified separately.
Table 4-1
Component
Name
PWBA ESS AIO
Stored Infor-
mation
Parameters that can be set by users (IP address, etc.)
- Job log
- Error log (Fault History, Counter)
- DV log/Auditron setting/ Total PV Information
- Network Settings Information
Work before
replacement/
abolition
- Initial Action
Back up data by printing reports and using tools, in order to set the data again.
Execute “Clear All NVMs” of “Installation” in Printer Diag of CE Mode.
Work after
replacement
- Handling the removed PWB
Be sure to initialize the PWB and then take it back to your base. If the PWB cannot be
initialized at the customer site, tell the customer the PWB will be initialized at the FX
recycling location and that no security problem will occur.
- Final Action
Restore the data, using tools.
Return settings to their original values, using reports.
To Next Page
