Chapter 2 Troubleshooting
2.3 Error Code FIP
2-85
FIP2.12 DRIVE ASSY MAIN (PL3.1.1)
Step Check and Action Yes No
Parts considered to be the cause
DRIVE ASSY MAIN (PL3.1.1)
HARNESS ASSY MAIN MOT (PL18.3.11)
PWB LVPS (PL18.1.5)
PWBA MCU (PL18.2.2)
1
Check for foreign substances in the DRIVE ASSY MAIN
Drive Section
Are there any foreign substances in the DRIVE ASSY
MAIN Drive Section?
Remove the
foreign sub-
stances
Go to Step 2.
2
Check the shape of the DRIVE ASSY MAIN
Is the DRIVE ASSY MAIN damaged?
Replace the
DRIVE ASSY
MAIN
(REP 3.1)
Go to Step 3.
3
Check connector connection
Check the connections between the DRIVE ASSY MAIN
and the PWBA MCU, as well as between the DRIVE
ASSY MAIN and the PWB LVPS.
Is the HARNESS ASSY MAIN MOT (P/J101-P/J10P/
J101-P/J212) connected securely?
Go to Step 4.
Securely con-
nect the HAR-
NESS ASSY
MAIN MOT (P/
J101-P/J10P/
J101-P/J212)
4
Check after replacing the DRIVE ASSY MAIN
Replace the DRIVE ASSY MAIN. (REP 3.1)
Does an error occur?
Go to Step 5. End of work.
5
Check after replacing the HARNESS ASSY MAIN MOT
Replace the HARNESS ASSY MAIN MOT.
Does an error occur?
Go to Step 6. End of work.
6
Check after replacing the PWB LVPS
Replace the PWB LVPS. (REP 18.4)
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
To Next Page
