Chapter 2 Troubleshooting
2.3 Error Code FIP
2-87
FIP2.14 MOTOR-ASSY OPTION (PL10.1.19) (Option)
Step Check and Action Yes No
Parts considered to be the cause
GEAR-OPT IDLER 250 (PL10.1.9)
GEAR-OPT FEEDER 250 (PL10.1.10)
MOTOR-ASSY OPTION (PL10.1.19)
HARNESS ASSY TRAY MOT (PL10.1.11)
PWBA ASSY OPT TRAY (PL10.1.5)
1
Check for foreign substances in the MOTOR-ASSY
OPTION Drive Section
Are there any foreign substances in the MOTOR-ASSY
OPTION Drive Section?
Remove the
foreign sub-
stances
Go to Step 2.
2
Check the shape of the GEAR-OPT IDLER 250 and the
GEAR-OPT FEEDER 250
Is the GEAR-OPT IDLER 250 or the GEAR-OPT FEEDER
250 damaged?
Replace the
GEAR-OPT
IDLER 250
and the
GEAR-OPT
FEEDER
250
Go to Step 3.
3
Check connector connection
Check the connection between the MOTOR-ASSY
OPTION and the PWBA ASSY OPT TRAY.
Is the HARNESS ASSY TRAY MOT (P/J4221-P/J422)
connected securely?
Go to Step 4.
Securely
connect the
HARNESS
ASSY TRAY
MOT
(P/J4221-P/
J422)
4
Check after replacing the MOTOR-ASSY OPTION
Replace the MOTOR-ASSY OPTION. (REP 10.7)
Does an error occur?
Go to Step 5. End of work.
5
Check after replacing the HARNESS ASSY TRAY MOT
Replace the HARNESS ASSY TRAY MOT.
Does an error occur?
Replace the
PWBA ASSY
OPT TRAY
(REP 10.3)
End of work.
To Next Page
