Chapter 2 Troubleshooting
2.4 Other FIP
2-92
FIP-P2 DC Power FIP
Step Yes No
Parts considered to be the cause
CONSOLE ASSY (PL1.1.1)
PWBA ESS (PL18.1.2)
PWB LVPS (PL18.1.5)
PWBA MCU (PL18.2.2)
1
Check the connection of the PWB LVPS connectors
Remove the Power Cord and wait for one minute.
Reinstall all of the connectors on the PWB LVPS.
Does the device operate?
End of work. Go to Step 2.
2
Check the connection of the CONSOLE ASSY connectors
Reinstall the CONSOLE ASSY connectors.
Does the device operate?
End of work. Go to Step 3.
3
Check the installation of the PWBA ESS
Reinstall the ESS PWBA.
Does the device operate?
End of work. Go to Step 4.
4
Check the installation of the PWBA MCU
Reinstall the PWBA MCU.
Does the device operate?
End of work.
Replace the
PWB LVPS
(REP18.4)
To Next Page
