Chapter 2 Troubleshooting
2.3 Error Code FIP
2-58
FIP1.13 050-132 IOT Remain Zone Regi + MSI + T1 + T2 Jam
050-133 IOT Zone MSI + T1 + T2 Jam
050-134 IOT Zone MSI + T1 Jam
050-142 IOT Remain Zone Regi + MSI + T1 Jam
Step Check and Action Yes No
Parts considered to be the cause
ROLL ASSY RUBBER (PL15.2.6)
ROLL ASSY REGI PINCH (PL15.2.8)
ROLL REGI PINCH (PL15.2.37)
MSI Feed Roll / Nudger Roll [HOLDER ASSY PICK UP]
(PL13.1.15)
KIT RETARD ROLL MSI ASSY(PL13.2.98)
Tray 1 Feed Roll / Nudger Roll [FEEDER ASSY] (PL15.3.2)
Tray 1 Retard Roll [HOLDER ASSY RETARD CST]
(PL9.1.3)
Transfer Unit [ROLL ASSY-TRANS CRU] (PL6.1.1)
Drum Cartridge [XERO ASSY] (PL8.1.1)
Tray 2 Feed Roll / Nudger Roll [ROLL ASSY FEED]
(PL10.2.13) (Option)
Tray 2 Retard Roll [HOLDER ASSY RETARD CST]
(PL10.3.3) (Option)
Regi. Sensor [HVPS] (PL18.2.5)
REGI. CLUTCH (PL15.2.4)
SOLENOID FEED MSI (PL13.1.5)
CST FEED CLUTCH (PL15.2.16)
CLUTCH ASSY OPT FEED (PL10.1.8) (Option)
MOTOR-ASSY OPTION (PL10.1.19) (Option)
DRIVE ASSY MAIN (PL3.1.1)
PWBA MCU (PL18.2.2)
1
Check the paper transport path
Is there any foreign substances or bits of paper found on
the paper transport path?
Remove the for-
eign sub-
stances and bits
of paper, etc.
Go to Step 2.
2
Check the paper feed rolls
Are the paper feed rolls (the rolls that are listed among the
parts considered to be the cause) installed properly?
Go to Step 3.
Reinstall the
correspond-
ing paper
feed rolls
3
Check the paper feed rolls
Are the paper feed rolls (the rolls that are listed among the
parts considered to be the cause in sequence) deformed or
worn out?
Replace the cor-
responding
paper feed rolls
Go to Step 4.
4
Check the Regi. Sensor [HVPS] operation
Execute the Diag Digital Input [071-102] to check the oper-
ation of the Regi. Sensor [HVPS].
Is the Regi. Sensor [HVPS] operating normally?
Go to Step 5. Go to FIP2.2
5
Check the REGI. CLUTCH operation
Execute the Diag Digital Output [071-006] to check the
operation of the REGI. CLUTCH.
Is the REGI. CLUTCH operating normally?
Go to Step 6. Go to FIP2.8
To Next Page
